Specifications :
Part No. | 9008211720 |
Electricals | |
Frequency range(MHz) | 3700-3840 |
Insertion Loss(dB) | ≤2.0(Full temperature) |
VSWR | ≤1.4 (25℃) |
Passband ripple(dB) | ≤1.7 (25℃) |
Out-of-Band Rejection | ≥50 dB @ 1-3400 MHz (25℃) ≥50 dB @ 3400-3690MHz (25℃) ≥50 dB @ 3850-4000MHz (25℃) ≥50 dB @ 4000-4200MHz (25℃) ≥50 dB @ 4200-4900MHz (25℃) |
Power | 5 W(Avg.) 50W(Peak) |
Impedance | 50Ω |
Operating temperature | -40℃~+85℃ |
Mechanicals | |
Connectors | SMA- Female |
Dimensions | 120*86*25mm(Screws included) |
Packing | 1pc/box |
Outline drawing :
