Electrical characteristics
Model No. | |
Frequency | 380-390MHz(DC-3GHz) |
VSWR | 1.2 |
Characteristic Impedance | 50 ohm |
Transmission power | 200W(MAX=400) |
Dielectric Withstanding Voltage | ≥2500V RMS,50hz,at sea level |
Working Voltage | ≤1000V RMS,50Hz,at sea level |
Rated DC voltage | 230V |
Maximum impluse discharge current | 20kA |
Ground wire diameter | ≤4 mm2 |
Dielectric Resistance | ≥5000MΩ |
Contact Resistance | Center Contact ≤0.4mΩ Outer Contact ≤0.4mΩ |
Meterial and plating
Material | plating | |
Body | Brass | Tri-Alloy |
Insulator | PTFE | - |
Center conductor | Brass | Au |
Connection sleeve | Brass | Ni |
Screw nut | Stainless steel | - |
Washer | Stainless steel | - |
Environmental
Temperature Range | -40℃ ~ +85℃ |
Relative humidity | ≤95%（Temperature 25℃±2℃） |
Durability | ≥500 cycles |
ROHS compliant | Full ROHS compliance |
Interface
According to | IEC 60169-16 |
