5 Watt 4.3/10-Male Termination

4.3-10 connector system is designed to meet the rising performance needs of mobile network equipment e.g. to connect the RRU to the antenna. The small size and low weight of these connectors do justice to the miniaturization of mobile radio network components. Despite their size, the connectors guarantee excellent return loss and passive inter-modulation performance (PIM) levels.

Always on time

Acceptable price

Excellent quality

Inquiry Now

download

Product Detail

Message

l Wide frequency range DC-4G MHZ for 2G/3G/4G applications ·

l Low passive intermodulation

l Low VSWR & insertion loss ·

l Indoor & outdoor use;

l Connector Type 4.3/10 Available

Specifications :

Part No.	HT-TER-50-4G-5W-43M(-100)
Operating Frequency Band	DC-4.0 GHz
Impendence	50 Ohm
VSWR	≤1.20
Input Power	5 Watt (avg.)
Connector	4.3/10 Male
Operating Temperature	-40 ℃ to + 80 ℃
Weight	55g
Connector Material	Brass
Inner Contact Plating of Connector	Silver
Outer Contact Plating of Connector	Nickel
Body Material	Aluminum
Environmental	Indoor Application
HT Part code	6008685005
